OBSAI & CPRI SFP
OBSAI & CPRI SFP
1 / 2
OBSAI & CPRI SFP
2 / 2

CPRI OBSAI SFP

The Common Public Radio Interface (CPRI) standard defines the interface of base stations between the Radio Equipment Controllers (REC) in the standard, to local or remote radio units, known as Radio Equipment (RE). The companies working to define the specification include Ericsson AB, Huawei Technologies Co. Ltd, NEC Corporation, Alcatel Lucent and Nokia Siemens Networks GmbH & Co. KG. OBSAI, which stands for "Open Base Station Architecture Initiative", is an initiative created by Hyundai, LGE, Nokia, Samsung and ZTE in September 2002 with the aim of creating an open market for cellular base stations. The idea behind this initiative was that an open market would substantially reduce the development effort and costs traditionally associated with creating new base station product ranges. LTE, an initialism of long-term evolution, marketed as 4G LTE, is a standard for wireless communication of high-speed data for mobile phones and data terminals. It is based on the GSM/EDGE and UMTS/HSPA network technologies, increasing the capacity and speed using a different radio interface together with core network improvements.

LTE (Long Term Evolution) is the project name of a new high performance air interface for cellular mobile communication systems. It is the last step toward the 4th generation (4G) of radio technologies designed to increase the capacity and speed of mobile telephone networks. Where the current generation of mobile telecommunication networks are collectively known as 3G (for "third generation"), LTE is marketed as 4G.

For the OBSAI application, the rates are 6.144 Gb/s, 3.072 Gb/s, 1.536 Gb/s, 0.768Gb/s

For the CPRI application, the rates are 9.830 Gb/s, 7.373Gb/s, 6.144 Gb/s, 4.915 Gb/s, 2.458 Gb/s, 1.229 Gb/s, 0.614Gb/s

    • Operating Data Rate up to 11.3Gbps
    • Distance up to 100km
    • Single 3.3V Power Supply and TTL Logic Interface
    • Duplex LC Connector Interface
    • Hot Pluggable
    • Power Dissipation < 1.0W
    • Compliant with MSA SFP+ Specification SFF-8431
    • Compliant with IEEE 802.3ae 10GBASE-LR/LW
    • Operating Case Temperature Standard: 0~+70C or Industrial: -40~+85C
    • Safety Certification: TUV/UL/FDA*Note1
    • RoHS Complian
    • 10GBASE-LR at 10.31 Gbps
    • 10GBASE-LW at 9.95 Gbps
    • OBSAI Rates 6.144 Gb/s, 3.072 Gb/s, 1.536 Gb/s, 0.768 Gb/s
    • CPRI Rates 10.138 Gb/s, 9.830 Gb/s, 7.373 Gb/s, 6.144 Gb/s, 4.915 Gb/s, 2.458 Gb/s, 1.229 Gb/s, 0.614 Gb/s
    • Other Optical Links
    OBSAI & CPRI SFP 0.614~11.1GOBSAI & CPRI SFP 0.614~8.5GOBSAI & CPRI SFP 0.614~6.25OBSAI & CPRI SFP 0.768~3.072

    OBSAI & CPRI SFP 0.614~11.1G

    Part No. Description Data Rate Wavelength Distance Connector Temp.
    EOLP-8596-02 CPRI & OBSAI SFP+ 0.614~11.1 850nm 0.3km LC C
    EOLP-8596-02-I CPRI & OBSAI SFP+ 0.614~11.1 850nm 0.3km LC I
    EOLP-1396-2M CPRI & OBSAI SFP+ 0.614~11.1 1310nm 2km LC C
    EOLP-1396-02 CPRI & OBSAI SFP+ 0.614~11.1 1310nm 2km LC C
    EOLP-1396-02-I CPRI & OBSAI SFP+ 0.614~11.1 1310nm 2km LC I
    EOLP-1396-10 CPRI & OBSAI SFP+ 0.614~11.1 1310nm 10km LC C
    EOLP-1396-10-I CPRI & OBSAI SFP+ 0.614~11.1 1310nm 10km LC I
    EOLP-1396-20 CPRI & OBSAI SFP+ 0.614~11.1 1310nm 20km LC C
    EOLP-1396-20-I CPRI & OBSAI SFP+ 0.614~11.1 1310nm 20km LC I
    EOLP-1396-40 CPRI & OBSAI SFP+ 0.614~11.1 1310nm 40km LC C
    EOLP-1396-40-I CPRI & OBSAI SFP+ 0.614~11.1 1310nm 40km LC I
    EOLP-1396-70 CPRI & OBSAI SFP+ 0.614~11.1 1310nm 70km LC C
    EOLP-1396-70 CPRI & OBSAI SFP+ 0.614~11.1 1310nm 70km LC I
    EOLP-1596-40-N CPRI & OBSAI SFP+ 0.614~11.1 1550nm 40km LC C
    EOLP-1596-40-IN CPRI & OBSAI SFP+ 0.614~11.1 1550nm 40km LC I
    EOLP-1596-80-N CPRI & OBSAI SFP+ 0.614~11.1 1550nm 80km LC C
    EOLP-1596-80-IN CPRI & OBSAI SFP+ 0.614~11.1 1550nm 80km LC I
    EOLP-1596-A-N CPRI & OBSAI SFP+ 0.614~11.1 1550nm 10km0 LC C
    EOLP-BI1696-3M-ADL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 150m LC C
    EOLP-BI1696-3M-DAL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 150m LC C
    EOLP-BI1696-3M-ADIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 150m LC I
    EOLP-BI1696-3M-DAIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 150m LC I
    EOLP-BI1696-9ADL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 9dB LC C
    EOLP-BI1696-9DAL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 9dB LC C
    EOLP-BI1696-9ADIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 9dB LC I
    EOLP-BI1696-9DAIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 9dB LC I
    EOLP-BI1696-12ADL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 12dB LC C
    EOLP-BI1696-12DAL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 12dB LC C
    EOLP-BI1696-12ADIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 12dB LC I
    EOLP-BI1696-12DAIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 12dB LC I
    EOLP-BI1696-16ADL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 16dB LC C
    EOLP-BI1696-16DAL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 16dB LC C
    EOLP-BI1696-16ADIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 16dB LC I
    EOLP-BI1696-16DAIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 16dB LC I
    EOLP-BI1696-21ADL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 21dB LC C
    EOLP-BI1696-21DAL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 21dB LC C
    EOLP-BI1696-21ADIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1270nm 21dB LC I
    EOLP-BI1696-21DAIL CPRI & OBSAI BIDI SFP+ 0.614~11.3 1330nm 21dB LC I
    EOLP-BI1696-9AD CPRI & OBSAI BIDI SFP+ 0.614~10.3 1270nm 9dB LC C
    EOLP-BI1696-9DA CPRI & OBSAI BIDI SFP+ 0.614~10.3 1330nm 9dB LC C
    EOLP-BI1696-9ADI CPRI & OBSAI BIDI SFP+ 0.614~10.3 1270nm 9dB LC E
    EOLP-BI1696-9DAI CPRI & OBSAI BIDI SFP+ 0.614~10.3 1330nm 9dB LC E
    EOLP-BI1696-12AD CPRI & OBSAI BIDI SFP+ 0.614~10.3 1270nm 12dB LC C
    EOLP-BI1696-12DA CPRI & OBSAI BIDI SFP+ 0.614~10.3 1330nm 12dB LC C
    EOLP-BI1696-12ADI CPRI & OBSAI BIDI SFP+ 0.614~10.3 1270nm 12dB LC E
    EOLP-BI1696-12DAI CPRI & OBSAI BIDI SFP+ 0.614~10.3 1330nm 12dB LC E
    EOLP-BI1696-14AD CPRI & OBSAI BIDI SFP+ 0.614~10.3 1270nm 14dB LC C
    EOLP-BI1696-14DA CPRI & OBSAI BIDI SFP+ 0.614~10.3 1330nm 14dB LC C
    EOLP-BI1696-14ADI CPRI & OBSAI BIDI SFP+ 0.614~10.3 1270nm 14dB LC E
    EOLP-BI1696-14DAI CPRI & OBSAI BIDI SFP+ 0.614~10.3 1330nm 14dB LC E
    EOLP-1696-10X CPRI & OBSAI CWDM SFP+ 0.614~11.1 CWDM (A~R) 10dB LC C
    EOLP-1696-14X CPRI & OBSAI CWDM SFP+ 0.614~11.1 CWDM (A~J) 14dB LC C
    EOLP-1696-14XN CPRI & OBSAI CWDM SFP+ 0.614~11.1 CWDM (K~R) 14dB LC C
    EOLP-1696-14XEN CPRI & OBSAI CWDM SFP+ 0.614~11.1 CWDM (K~R) 14dB LC E
    EOLP-1696-23X CPRI & OBSAI CWDM SFP+ 0.614~11.1 CWDM (A~J) 23dB LC C
    EOLP-1696-23XN CPRI & OBSAI CWDM SFP+ 0.614~11.1 CWDM (K~R) 23dB LC C
    EOLP-1696-23XEN CPRI & OBSAI CWDM SFP+ 0.614~11.1 CWDM (K~R) 23dB LC E
    EOLP-1696-14XXN CPRI & OBSAI DWDM SFP+ 0.614~11.1 DWDM 100GHz 14dB LC C
    EOLP-1696-14XXIN CPRI & OBSAI DWDM SFP+ 0.614~11.1 DWDM 100Ghz 14dB LC I
    EOLP-1696-14XXXN CPRI & OBSAI DWDM SFP+ 0.614~11.1 DWDM 50GHz 14dB LC C
    EOLP-1696-14XXXEN CPRI & OBSAI DWDM SFP+ 0.614~11.1 DWDM 50Ghz 14dB LC E
    EOLP-1696-23XXN CPRI & OBSAI DWDM SFP+ 0.614~11.1 DWDM 100GHz 23dB LC C
    EOLP-1696-23XXEN CPRI & OBSAI DWDM SFP+ 0.614~11.1 DWDM 100Ghz 23dB LC E
    EOLP-1696-23XXXN CPRI & OBSAI DWDM SFP+ 0.614~11.1 DWDM 50GHz 23dB LC C
    EOLP-1696-23XXXEN CPRI & OBSAI DWDM SFP+ 0.614~11.1 DWDM 50Ghz 23dB LC E

    For the latest specification and samples, please, contact us This email address is being protected from spambots. You need JavaScript enabled to view it.

    OBSAI & CPRI SFP 0.614~8.5G

    Part No. Description Data Rate Wavelength Distance Connector Temp.
    EOLP-8580-02 CPRI & OBSAI SFP 0.614~8.5 850nm 0.3km LC C
    EOLP-8580-02-I CPRI & OBSAI SFP 0.614~8.5 850nm 0.3km LC I
    EOLP-1380-02 CPRI & OBSAI SFP 0.614~8.5 1310nm 1.4km LC C
    EOLP-1380-02-I CPRI & OBSAI SFP 0.614~8.5 1310nm 1.4km LC I
    EOLP-1380-10 CPRI & OBSAI SFP 0.614~8.5 1310nm 10km LC C
    EOLP-1380-10-I CPRI & OBSAI SFP 0.614~8.5 1310nm 10km LC I
    EOLP-1380-20 CPRI & OBSAI SFP 0.614~8.5 1310nm 20km LC C
    EOLP-1380-20-I CPRI & OBSAI SFP 0.614~8.5 1310nm 20km LC I
    EOLP-1380-40 CPRI & OBSAI SFP 0.614~8.5 1310nm 40km LC C
    EOLP-1380-40-I CPRI & OBSAI SFP 0.614~8.5 1310nm 40km LC I
    EOLP-1580-80-N CPRI & OBSAI SFP 0.614~8.5 1550nm 80km LC C
    EOLP-1580-80-IN CPRI & OBSAI SFP 0.614~8.5 1550nm 80km LC I
    EOLP-1680-10X CPRI & OBSAI CWDM SFP 0.614~8.5 CWDM 10dB LC E
    EOLP-1680-14XN CPRI & OBSAI CWDM SFP 0.614~8.5 CWDM (K~R) 14dB LC C
    EOLP-1680-14XIN CPRI & OBSAI CWDM SFP 0.614~8.5 CWDM (K~R) 14dB LC I
    EOLP-1680-23XN CPRI & OBSAI CWDM SFP 0.614~8.5 CWDM (K~R) 23dB LC C
    EOLP-1680-23XIN CPRI & OBSAI CWDM SFP 0.614~8.5 CWDM (K~R) 23dB LC I
    EOLP-1680-14XXN CPRI & OBSAI DWDM SFP 0.614~8.5 DWDM 100GHz 14dB LC C
    EOLP-1680-14XXIN CPRI & OBSAI DWDM SFP 0.614~8.5 DWDM 100GHz 14dB LC I
    EOLP-1680-23XXN CPRI & OBSAI DWDM SFP 0.614~8.5 DWDM 100GHz 23dB LC C
    EOLP-1680-23XXIN CPRI & OBSAI DWDM SFP 0.614~8.5 DWDM 100GHz 23dB LC I

    For the latest specification and samples, please, contact us This email address is being protected from spambots. You need JavaScript enabled to view it.

    OBSAI & CPRI SFP 0.614~6.25

    Part No. Description Data Rate Wavelength Distance Connector Temp.
    EOLP-8560-02 CPRI & OBSAI SFP 0.614~6.25 850nm 0.3km LC C
    EOLP-8560-02-I CPRI & OBSAI SFP 0.614~6.25 850nm 0.3km LC I
    EOLP-1360-02 CPRI & OBSAI SFP 0.614~6.25 1310nm 2km LC C
    EOLP-1360-02-I CPRI & OBSAI SFP 0.614~6.25 1310nm 2km LC I
    EOLP-1360-10 CPRI & OBSAI SFP 0.614~6.25 1310nm 10km LC C
    EOLP-1360-10-I CPRI & OBSAI SFP 0.614~6.25 1310nm 10km LC I
    EOLP-1560-40-N CPRI & OBSAI SFP 0.614~6.25 1550nm 40km LC C
    EOLP-1560-40-IN CPRI & OBSAI SFP 0.614~6.25 1550nm 40km LC I
    EOLP-1560-80-N CPRI & OBSAI SFP 0.614~6.25 1550nm 80km LC C
    EOLP-1560-80-IN CPRI & OBSAI SFP 0.614~6.25 1550nm 80km LC I
    EOLP-BI1660-9ADL CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 9dB LC C
    EOLP-BI1660-9DAL CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 9dB LC C
    EOLP-BI1660-9ADIL CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 9dB LC I
    EOLP-BI1660-9DAIL CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 9dB LC I
    EOLP-BI1660-12ADL CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 12dB LC C
    EOLP-BI1660-12DAL CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 12dB LC C
    EOLP-BI1660-12ADIL CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 12dB LC I
    EOLP-BI1660-12DAIL CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 12dB LC I
    EOLP-BI1660-16ADL CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 16dB LC C
    EOLP-BI1660-16DAL CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 16dB LC C
    EOLP-BI1660-16ADIL CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 16dB LC I
    EOLP-BI1660-16DAIL CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 16dB LC I
    EOLP-BI1660-21ADL CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 21dB LC C
    EOLP-BI1660-21DAL CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 21dB LC C
    EOLP-BI1660-21ADIL CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 21dB LC I
    EOLP-BI1660-21DAIL CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 21dB LC I
    EOLP-BI1660-9AD CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 9dB LC C
    EOLP-BI1660-9DA CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 9dB LC C
    EOLP-BI1660-9ADI CPRI & OBSAI BIDI SFP 0.614~6.25 1270nm 9dB LC E
    EOLP-BI1660-9DAI CPRI & OBSAI BIDI SFP 0.614~6.25 1330nm 9dB LC E
    EOLP-1660-10X CPRI & OBSAI CWDM SFP 0.614~6.25 CWDM(A~R) 10dB LC C
    EOLP-1660-14X CPRI & OBSAI CWDM SFP 0.614~6.25 CWDM(A~R) 14dB LC C
    EOLP-1660-22X CPRI & OBSAI CWDM SFP 0.614~6.25 CWDM(A~R) 22dB LC C
    EOLP-1660-14XXN CPRI & OBSAI DWDM SFP 0.614~6.25 DWDM 100GHz 14dB LC C
    EOLP-1660-14XXIN CPRI & OBSAI DWDM SFP 0.614~6.25 DWDM 100Ghz 14dB LC I
    EOLP-1660-23XXN CPRI & OBSAI DWDM SFP 0.614~6.25 DWDM 100GHz 23dB LC C
    EOLP-1660-23XXEN CPRI & OBSAI DWDM SFP 0.614~6.25 DWDM 100GHz 23dB LC E
    EOLP-1660-14XXXN CPRI & OBSAI DWDM SFP 0.614~6.25 DWDM 50GHz 14dB LC C
    EOLP-1660-23XXXN CPRI & OBSAI DWDM SFP 0.614~6.25 DWDM 50GHz 23dB LC C

    For the latest specification and samples, please, contact us This email address is being protected from spambots. You need JavaScript enabled to view it.

    OBSAI & CPRI SFP 0.768~3.072

    Part No. Description Data Rate Wavelength Distance Connector Temp.
    EOLS-8531-02 CPRI & OBSAI SFP 0.768~3.072 850nm 0.4km LC C
    EOLS-8531-02-I CPRI & OBSAI SFP 0.768~3.072 850nm 0.4km LC I
    EOLS-8531-02-D CPRI & OBSAI SFP 0.768~3.072 850nm 0.4km LC C
    EOLS-8531-02-DI CPRI & OBSAI SFP 0.768~3.072 850nm 0.4km LC I
    EOLS-1331-07 CPRI & OBSAI SFP 0.768~3.072 1310nm 7km LC C
    EOLS-1331-07-I CPRI & OBSAI SFP 0.768~3.072 1310nm 7km LC I
    EOLS-1331-07-D CPRI & OBSAI SFP 0.768~3.072 1310nm 7km LC C
    EOLS-1331-07-DI CPRI & OBSAI SFP 0.768~3.072 1310nm 7km LC I
    EOLS-1331-20 CPRI & OBSAI SFP 0.768~3.073 1310nm 20km LC C
    EOLS-1331-20-I CPRI & OBSAI SFP 0.768~3.074 1310nm 20km LC I
    EOLS-1331-20-D CPRI & OBSAI SFP 0.768~3.075 1310nm 20km LC C
    EOLS-8531-02-I CPRI & OBSAI SFP 0.768~3.076 1310nm 20km LC I
    EOLS-1531-40 CPRI & OBSAI SFP 0.768~3.076 1550nm 40km LC C
    EOLS-1531-40-I CPRI & OBSAI SFP 0.768~3.076 1550nm 40km LC I
    EOLS-1531-40-D CPRI & OBSAI SFP 0.768~3.076 1550nm 40km LC C
    EOLS-1531-40-DI CPRI & OBSAI SFP 0.768~3.076 1550nm 40km LC I
    EOLS-1531-80 CPRI & OBSAI SFP 0.768~3.076 1550nm 80km LC C
    EOLS-1531-80-I CPRI & OBSAI SFP 0.768~3.076 1550nm 80km LC I
    EOLS-1531-80-D CPRI & OBSAI SFP 0.768~3.076 1550nm 80km LC C
    EOLS-1531-80-DI CPRI & OBSAI SFP 0.768~3.076 1550nm 80km LC I
    EOLS-BI1331-10 CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 10km LC C
    EOLS-BI1531-10 CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 10km LC C
    EOLS-BI1331-10-I CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 10km LC I
    EOLS-BI1531-10-I CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 10km LC I
    EOLS-BI1331-10-D CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 10km LC C
    EOLS-BI1531-10-D CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 10km LC C
    EOLS-BI1331-20 CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 20km LC C
    EOLS-BI1531-20 CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 20km LC C
    EOLS-BI1331-20-I CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 20km LC I
    EOLS-BI1531-20-I CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 20km LC I
    EOLS-BI1331-20-D CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 20km LC C
    EOLS-BI1531-20-D CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 20km LC C
    EOLS-BI1331-20-DI CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 20km LC I
    EOLS-BI1531-20-DI CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 20km LC I
    EOLS-BI1331-40 CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 40km LC C
    EOLS-BI1531-40 CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 40km LC C
    EOLS-BI1331-40-I CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 40km LC I
    EOLS-BI1531-40-I CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 40km LC I
    EOLS-BI1331-40-D CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 40km LC C
    EOLS-BI1531-40-D CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 40km LC C
    EOLS-BI1331-40-DI CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 40km LC I
    EOLS-BI1531-40-DI CPRI & OBSAI BIDI SFP 0.768~3.076 1550nm 40km LC I
    EOLS-BI1631-20-CL CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 20km LC C
    EOLS-BI1631-20-LC CPRI & OBSAI BIDI SFP 0.768~3.076 1490 20km LC C
    EOLS-BI1631-20-CLI CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 20km LC I
    EOLS-BI1631-20-LCI CPRI & OBSAI BIDI SFP 0.768~3.076 1490 20km LC I
    EOLS-BI1631-20-CLD CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 20km LC C
    EOLS-BI1631-20-LCD CPRI & OBSAI BIDI SFP 0.768~3.076 1490 20km LC C
    EOLS-BI1631-20-CLDI CPRI & OBSAI BIDI SFP 0.768~3.076 1310nm 20km LC I
    EOLS-BI1631-20-LCDI CPRI & OBSAI BIDI SFP 0.768~3.076 1490 20km LC I
    EOLS-1631-13XD CPRI & OBSAI CWDM SFP 0.768~3.076 CWDM 13dB LC C
    EOLS-1631-13XDI CPRI & OBSAI CWDM SFP 0.768~3.076 CWDM 13dB LC E
    EOLS-1631-18XD CPRI & OBSAI CWDM SFP 0.768~3.076 CWDM 18dB LC C
    EOLS-1631-18XDI CPRI & OBSAI CWDM SFP 0.768~3.076 CWDM 18dB LC E
    EOLS-1631-24XD CPRI & OBSAI CWDM SFP 0.768~3.076 CWDM 24dB LC C
    EOLS-1631-24XDI CPRI & OBSAI CWDM SFP 0.768~3.076 CWDM 24dB LC E
    EOLS-1631-18XXD CPRI & OBSAI DWDM SFP 0.768~3.076 DWDM 100GHz 18dB LC C
    EOLS-1631-18XXDI CPRI & OBSAI DWDM SFP 0.768~3.076 DWDM 100GHz 18dB LC E
    EOLS-1631-24XXD CPRI & OBSAI DWDM SFP 0.768~3.076 DWDM 100GHz 24dB LC C
    EOLS-1631-24XXDI CPRI & OBSAI DWDM SFP 0.768~3.076 DWDM 100GHz 24dB LC E
    EOLS-1631-18XXXD CPRI & OBSAI DWDM SFP 0.768~3.076 DWDM 50GHz 18dB LC C
    EOLS-1631-18XXXDI CPRI & OBSAI DWDM SFP 0.768~3.076 DWDM 50GHz 18dB LC E
    EOLS-1631-24XXXD CPRI & OBSAI DWDM SFP 0.768~3.076 DWDM 50GHz 24dB LC C
    EOLS-1631-24XXXDI CPRI & OBSAI DWDM SFP 0.768~3.076 DWDM 50GHz 24dB LC E

    For the latest specification and samples, please, contact us This email address is being protected from spambots. You need JavaScript enabled to view it.

    Eoptolink

    Connect

    Contact our global sales team

    This email address is being protected from spambots. You need JavaScript enabled to view it.

    Contacts

    Please complete all required fields!

    Invalid Input
    Invalid Input
    Invalid Input

    Newsletter

    Please complete all required fields!

    Sign up to our Newsletter to be the first to know about latest optical transceiver releases.
    Invalid Input

    Follow Us

    Copyright © 2021 Eoptolink Technology Inc., Ltd. All rights reserved.
    X

    Main Menu

    • Product solutions
      • 1.6T
      • 800G
      • 400G
      • 200G
      • 100G
      • 50G
      • 40G
      • 25G
      • 10G
      • Lower than 10G
      • xPON
      • Other
      • OSA
    • About Us
    • Newsroom
    • Support
    • Partners
