OSFP 8x100G DR MCF
1 / 1

800G OSFP MCF

Eoptolink’s OSFP transceiver module with dual MPO-12 based 4CF interface is designed for use in 800 Gigabit Ethernet links over 500m matched 4CF single mode fiber. The firmware supports CMIS 5.0 and newer release.

    • Supports 850Gb/s
    • Single 3.3V Power Supply
    • OSFP MSA Compliant
    • 0 to 500m over matched 4CF with KP4 FEC supported at the Host side
    • Dual MPO-12 connector with 4 core fiber design
    • 8x106.25 Gb/s (PAM4) optical interface
    • 8x106.25 Gb/s (PAM4) electrical interface
    • Commercial case temperature range of 0°C to 70°C
    • CMIS 5.0 or later version
    Part No. Description Data Rate Wavelength Distance Connector Temp.
    EOLO-138HG-5H-SDM34 OSFP 800G DR8 8x100G 800GbE 1310nm 500m Dual MPO-12 0-70°C

    For the latest specification and samples, please, contact us This email address is being protected from spambots. You need JavaScript enabled to view it.
